I copied the circuit layout of my Kalamazoo amp onto paper last night. This circuit will be the basis of the custom amp I'm building for my friend in New Orleans. The simplest possible circuit for the truest, rawest, most honest tone.
Here's the only control that will be on the faceplate.
I think it's important to have a cool volume knob. If you're going to have only one knob, it'd better be a good looking one.
